EPC050101F245V1 SMD Antenna, 5.5x1.2x1.2mm, 2.4G, Bluetooth, ZigBee, Wireless, HomeRF
Approval Sheet Download(Click Me)
FEATURES
1. Surface Mounted Devices (SMD) with a small dimension of 5.5 x 1.2 x 1.2 mm3 meet miniaturization trend.
2. Low power loss and high antenna efficiency.
3. High stability in Temperature and Humidity Change.
APPLICATIONS
1. 2.4GHz ISM band RF applications
2. Bluetooth, ZigBee, Wireless, HomeRF
ELECTRICAL CHARACTERISTICS
|
Working Frequency Range |
2450±50MHz |
|
Band Width |
>100MHz |
|
Impedance |
50Ω |
|
Gain(dBi) |
4.0 (peak) |
|
VSWR |
<2 |
|
Operation Temperature |
-40℃~+95℃ |
|
Power Capacity |
3W |
STORAGE ENVIRONMENT CONDITON
1. Products shoud be storage in the warehouse on the following conditions:
Temperature: -10℃~+40℃
Humidity: 30% to 70% relative humidity
2. Don’t keep products in corrosive gases such as sulfur. Chlorine gas or acid or it may cause oxidization of electrode, resulting in poor solderability.
3. Products should be storage on the palette for the prevention of the influence from humidity, dust and so on.
4. Products should be storage in the warehouse without heat shock, vibration, direct sunlight and so on.
5. Products should be storage under the airtight packaged condition.
